OPERATOR EASE

• One man operation.
• Easy load hopper holds three minutes of stock.
• Single adjustment for size changes.
• Easy view operators panel with warning lights.
• Resetable peice counter.
• Totally enclosed for operator safety.
• 6″ dust collector port.
• Quick open access panel for blade changing.
• Automatic line filter, regulator, oiler.
• Low air pressure cut out.

LOW MAINTENANCE

• TEFC motors
• Standard sealed bearings.
• Easy access grease points.
• Removable panels.
• Automatic oiler.
• Pneumatic operation.

CONSTRUCTION

• Heavy wall tube frame.
• Heavy sheet metal guards.
• Fork lift points.
• Easy open access panels.
• Chain driven hopper.
• Powder coat finish

SPECIFICATIONS

• 900 hubs per hour@ 100 psi
• 33 cu ft/min.@ 100 psi
• 3phase 30 amp 220/440v
• 2- 14″ blades
• Hub size 1-1/2″ x 1-1/2″ (+ – 1/16″)
• Hub length 10″ – 24″
• Hopper capacity 48 pcs.
• Footprint 5’W x 8’L x 5.5’H
• Weight 2200Lbs

OPTIONS

• Single or three phase electric.
• Automatic shutdown counter.
• Waste conveyor.
• Stacking tables.
• Finished product conveyor.
• Automatic hub bander.
• Extended hopper.
• Larger capacity for hub length.
